EUMETCast Europe - Link Margin comparison
Levels   SNR   Link Margin   BER   Bad DVB packets & frames   TelliCast losses   RX I/O   PC I/O   RAMdisk   T1/T2   Using MRTG   EUMETCast status

BAS full traffic
Edinburgh, GB
125 cm dish, Titanium LNB, ~20 m cable
PC Penguin, i5-8400, Ayecka SR1 receiver #1
TelliCast 2.14.6, BS RX & process, Win-10/64 Pro

Missed & recovered packets
Edinburgh, GB
125 cm dish, Titanium LNB, ~20 m cable
PC Penguin, i5-8400, Ayecka SR1 receiver #1
TelliCast 2.14.6, BS RX & process, Win-10/64 Pro
Missed & recovered TelliCast packet rates
's-Gravendeel, NL   Summary page
TBS6983 PCIe card in PC P1
90 cm Wavefrontier, Inverto Ultra LNB, 20 m cable
Missed & recovered TelliCast packet rates


EUMETCast Europe - Link Margin comparison

Transponder 2
Edinburgh, GB
125 cm dish, Titanium LNB, ~12 m cable+splitter
PC Lund, Intel i5-6400, TBS6903, BDADataEx 1.1.4.9
TelliCast 2.14.5, HVS-1&2 RX only, Win-10/64 Pro
High Volume Service 2 link margin
Transponder 1
Edinburgh, GB   Summary page
Ayecka SR1 receiver #2
125 cm dish, Titanium quad LNB, ~10 m cable
HVS-1 only
High Volume Service 1 link margin

SNR difference between
transponders 1 and 2

Transponder 2
Nieuwe-Tonge, NL
TBS6903 receiver, two separate LNB feeds
150 cm dish, Inverto Octo LNB, 20 m cable
High Volume Service 2 link margin
Transponder 1
Nieuwe-Tonge, NL
TBS6903 receiver, two separate LNB feeds
150 cm dish, Inverto Octo LNB, 20 m cable
High Volume Service 1 link margin

Transponder 2
Naila, DE  Summary page
Novra S300E receiver
125 cm dish, Inverto Black Ultra LNB, ~20 m cable
High Volume Service 2 link margin
Transponder 1
Naila, DE  Summary page
Novra S300N receiver
125 cm dish, Inverto Black Ultra LNB, ~20 m cable
Basic & High Volume service margins

WXstn - location operates a weather station - click the link to see the weather status.

Other periods: day week month year
