EUMETCast Europe - Link Margin
Levels SNR Link Margin BER Bad DVB packets & frames TelliCast losses RX I/O PC I/O RAMdisk T1/T2 Using MRTG EUMETCast status
| Link margin should be greater than 4 dB for each service for optimum relability - Transponder 2 | ||
 | Edinburgh, GB Summary page Ayecka SR1 receiver #1 125 cm dish, Titanium quad LNB, ~20 m cable Basic service & HVS-1 link margin | |
 | Darlington, County Durham, GB WXstn Summary page Ayecka SR1 receiver 100 cm dish, Inverto Ultra Quad LNB, 12 m cable Basic service & HVS-1 link margin | |
 | Prescot, Merseyside, GB WXstn Ayecka SR1 receiver 88 cm dish ~30 m cable Basic service & HVS-1 link margin | |
 | Loughborough, GB WXstn Ayecka SR1 receiver 110 cm dish, Inverto Black Ultra LNB Basic service & HVS-1 link margin | |
 | 's-Gravendeel, NL Summary page TBS6983 PCIe card in PC P1 90 cm Wavefrontier, Inverto Ultra LNB, 20 m cable HVS-1 link margin | |
 | Nieuwe-Tonge, NL TBS6908 receiver, separate LNB feeds 150 cm dish, Maximum Pro Line LNB, 20 m cable Basic service & HVS-1 link margin | |
 | Mizen Peninsula, IE WXstn Ayecka SR1 receiver 130 cm dish Basic service & HVS-1 link margin | |
 | Porthcawl, Wales, GB WXstn Summary page TBS6903 single-cable receiver 88 cm dish, ~16 m cable HVS-1 link margin | |
 | Petersfield, Hampshire, GB Ayecka SR1 receiver - TP1 120 cm dish, Inverto Black, ~30 m cable Still E10B... Basic service & HVS-1 link margin | |
 | Brussels, BE Summary page Newtec MDM6000 receiver 180 cm dish, Swedish microwave LNB, 90 m cable Basic service & HVS-1 link margin | |
 | Naila, DE Summary page Novra S300N receiver 125 cm dish, Inverto Black Ultra LNB, ~20 m cable Basic service & HVS-1 link margin |
WXstn - location operates a weather station - click the link to see the weather status.
Other periods: day week month year
Transponder 2
 | Edinburgh, GB 125 cm dish, Titanium LNB, ~12 m cable+splitter PC Lund, Intel i5-6400, TBS6903, BDADataEx 1.1.4.9 TelliCast 2.14.7, 11470V HVS-2 RX only, Win-10/64 Pro | |
 | Edinburgh, GB 125 cm dish, Titanium LNB, ~20 m cable + 2*splitter 11470V Ayecka SR1 #3 | |
 | Darlington, County Durham, GB WXstn Summary page TBS6903 PCIe 100 cm dish, Inverto Ultra Quad LNB, 12 m cable | |
 | 's-Gravendeel, NL Summary page TBS6983 PCIe card in PC P1 90 cm Wavefrontier, Inverto Ultra LNB, 20 m cable | |
 | Nieuwe-Tonge, NL TBS6908 receiver, separate LNB feeds 150 cm dish, Maximum Pro Line LNB, 20 m cable | |
 | Porthcawl, Wales, GB WXstn Summary page Ayecka SR1 receiver 88 cm dish, ~16 m cable | |
 | Petersfield, Hampshire, GB Ayecka SR1 receiver #2 - TP2 120 cm dish, Inverto Black, ~30 m cable Still E10B... | |
 | Naila, DE Summary page Novra S300E receiver 125 cm dish, Inverto Black Ultra LNB, ~20 m cable |
Other periods for Transponder 2: day week month year
