GPS DOP and millimetre error - Edinburgh, Scotland
All data from Raspberry Pi 4 (2 GB RasPi-25) using a Uputronics GPS/RTC module with an outdoor antenna.
The u-blox MAX-M8Q-0-10 module is set to use the GPS, GLONASS & Galileo constellations. Location: 55.9° N, 3.2° W
Values are those reported by the u-blox firmware.
Estimated position error - peaks well above the average may indicate solar storm activity |
|
 |
2D error (EPH) Altitude error (EPV) (smaller is better) |
DOP - Dilution of Precision |
|
 |
Horizontal DOP Vertical DOP (smaller is better) |
Number of satellites visible and used |
|
 |
Potentially visible Actually used |
Average SNR |
|
 |
GPS SNR average |
